1 934C036O01 TERMINAL PCB ASSY
*
!
2 935C989O01 INLET PCB ASSY
*
!
3 935B279O03 MAIN PCB ASSY [SL2U]
*
!
3 935B279O01 MAIN PCB ASSY [XL2U]
4
-----
TERMINAL SHIELD
5 288P227O10 COOLING FAN (POWER)
6
-----
INLET BARRIER
7 433C026O20 SEESAW SW
1
-----
POWER BARRIER
*
!
2 935B270O01 POWER PCB ASSY
3
-----
POWER HOLDER
4
-----
POWER EARTH
1
-----
AUDIO BARRIER
*
!
2 935C990O01 AUDIO PCB ASSY
3
-----
AUDIO HOLDER
*
!
1 935D615O01 PREAMP PCB ASSY
*
!
2 939P875O10 LAMP POWER UNIT [SL2U]
*
!
2 939P931O10 LAMP POWER UNIT [XL2U]
3
-----
LAMP POWER HOLDER
ITEM
NO.
PARTS NO. PARTS NAME
EXPOSED VIEW
DESCRIPTION
TERMINAL ASSY (MAIN PCB ASSY, INLET PCB ASSY, TERMINAL PCB ASSY) (Fig. 2-2)
POWER ASSY (Fig. 2-3)
AUDIO ASSY (Fig. 2-4)
The PARTS on this page correspond to ones on page 5 and 6 in the EXPOSED file.
-
4
-
LAMP POWER ASSY (Fig. 2-5)
