Mitsubishi XL1X S L 2 Service Manual

288P227O10 COOLING FAN (POWER)
499D039O50 LCD BLOCK [S]
499D039O20 LCD BLOCK [X]
480P068O10 SPEAKER
499D029O60 THERMISTOR ASSY
! 499D029O90 THERMAL PROTECTOR
452C233O20 CARD LEAD SOCKET (SB)
452C247O20 CARD LEAD SOCKET (SG)
452C247O20 CARD LEAD SOCKET (SR)
! F901 283D107O30 FUSE T6.3AH 250V
J2M0 440C411O10 JACK BOARD
J2M1 440C388O10 PIN JACK BOARD 2PIN
J700 451C224O10 MINI DIN SOCKET
! J9F1 451D084O20 POWER JACK 3P
! PC901 268P103O10 PHOTO COUPLER TLP421F
! PC950 268P103O10 PHOTO COUPLER TLP421F
! RV9F1 265P100O30 VARISTOR ERZV10D511
! RV9F2 265P100O30 VARISTOR ERZV10D511
! SA9F1 299P220O20 SURGE SUPPRESSOR DSS-302M
X2A0 285P387O10 CRYSTAL RESONATOR 24.576MHz
X700 285P399O40 CRYSTAL RESONATOR 20.000MHz
X701 285P399O50 CRYSTAL RESONATOR 40.000MHz [S]
X701 285P399O60 CRYSTAL RESONATOR 65.000MHz [X]
X7A0 299P248O10 CERAMIC RESONATOR CSTCW24.00MX01 [X]
Z7U1 939P874O10 PREAMP UNIT TSOP4838XG1
Z7U2 939P874O10 PREAMP UNIT TSOP4838XG1
! Z900 299P194O20 THERMAL PROTECTOR 67L100-S
Z950 299P239O80 CURRENT PROTECTOR FUSE 3.15A
Z951 299P239O80 CURRENT PROTECTOR FUSE 3.15A
Z952 299P239O80 CURRENT PROTECTOR FUSE 3.15A
Z953 299P239O80 CURRENT PROTECTOR FUSE 3.15A
Z954 299P239O80 CURRENT PROTECTOR FUSE 3.15A
Z955 299P239O80 CURRENT PROTECTOR FUSE 3.15A
PRINTED CIRCUIT BOARD ASSY’S
* ! 935C990O01 AUDIO PCB ASSY
* ! 935C989O01 INLET PCB ASSY
* ! 935B279O03 MAIN PCB ASSY [S]
* ! 935B279O01 MAIN PCB ASSY [X]
* ! 935B270O01 POWER PCB ASSY
* ! 935D615O01 PREAMP PCB ASSY
* ! 935D617O01 SENSOR PCB ASSY
* ! 934C036O01 TERMINAL PCB ASSY
* ! 939P875O10 LAMP POWER UNIT [S]
* ! 939P931O10 LAMP POWER UNIT [X]
MECHANICAL PARTS
436P021O10 MICRO SWITCH MXS00621NLB1
674D123O10 INSERT NUT
674D126O10 NUT
683D048O10 WASHER 0.45X4.3X8.5
669D245O20 SCREW M4X0.7-10
669D396O60 SCREW 3.0X10
669D535O10 SCREW NO4-40UNC-11.8
669D561O50 SCREW FE SWCH 8A
669D199O30 SCREW
669D220O20 SCREW 3X8 46LA005
669D220O30 SCREW 3X10 46LA005
669D212O20 SCREW 3X8 83AF
669D329O20 SCREW M3X0.5-8
669D329O70 SCREW M3X0.5-30 8
669D364O10 SCREW
669D522O60 SCREW 2 L=10
669D329O30 SCREW (D901) M3X0.5-10
669D329O30 SCREW (Q900) M3X0.5-10
669D329O10 SCREW (Z900) M3X0.5-6
669D571O10 SCREW
COSMETIC PARTS
589B014O10 ADJUSTMENT FOOT
499D029O10 LAMP CASE ASSY [S]
499D039O40 LAMP CASE ASSY [X]
499D029O30 LENS CAP
975D152O70 TOP CASE ASSY [S]
750A472O10 TOP CASE ASSY [X]
620D053O20 AIR FILTER
752C265O20 FILTER COVER
! 253P158O10 LAMP [S]
! 499D039O90 LAMP [X]
752C271O00 LAMP COVER
499D029O20 LENS UNIT
499D039O60 POLARIZER(RGB) [S]
499D039O80 POLARIZER(RGB) [S]
499D039O30 POLARIZER(RGB) [X]
499D039O70 POLARIZER(RGB) [X]
761B381O80 TERMINAL BOARD [S]
761B381O70 TERMINAL BOARD [X]
750A473O30 BOTTOM CASE UNIT [S]
750A473O10 BOTTOM CASE UNIT [X]
499D030O10 PBS UNIT
PACKING PARTS AND ACCESSORY
1 772P037O10 SOFT CASE
2 803A582O10 PACKING CUSHION TOP/BOTTOM
3 831D190O10 PACKING SHEET 900X900
4 802B862O30 PACKING CASE [S]
4 802B862O10 PACKING CASE [X]
6, 11 831D337O10 PACKING BAG
7 871D361O30 INSTRUCTION BOOK [S]
7 871D361O10 INSTRUCTION BOOK [X]
* 9 939P928O10 REMOTE HAND UNIT [S]
* 9 939P927O10 REMOTE HAND UNIT [X]
! 12 246C383O10 AC POWER CORD
! 13 246C383O20 AC POWER CORD
14 246C447O10 CABLE CONTROL
15 246C448O10 CABLE VGA
16 246C381O10 CABLE AV
17 246C449O10 ADAPTOR PS/2 [X]
18 246C450O10 USB CABLE [X]
OTHER CRITICAL COMPONENTS
! R9F1 109D036O30 R-COMPOSITION 1/2W 1.0MΩ-K
! R9F2 109D036O20 R-COMPOSITION 1/2W 4.7MΩ-K
SYMBOL PA RTS
PARTS NAME DESCRIPTION
No. No.
SYMBOL PART S
PARTS NAME DESCRIPTION
No. No.
-
16 -
[S] : SL2U [X] : XL2U
