Mitsubishi XL1XU Service Manual

C2A1 141P142O90 CHIP CAPACITOR B25V/16V 0.047µF-K
C2A2 141P142O90 CHIP CAPACITOR B25V/16V 0.047µF-K
C2A3 141P142O90 CHIP CAPACITOR B25V/16V 0.047µF-K
C2A4 141P142O90 CHIP CAPACITOR B25V/16V 0.047µF-K
C2B0 141P142O90 CHIP CAPACITOR B25V/16V 0.047µF-K
C2B1 141P142O90 CHIP CAPACITOR B25V/16V 0.047µF-K
C2B2 141P142O90 CHIP CAPACITOR B25V/16V 0.047µF-K
C2B3 141P142O90 CHIP CAPACITOR B25V/16V 0.047µF-K
C2B4 141P142O90 CHIP CAPACITOR B25V/16V 0.047µF-K
C2C0 141P142O90 CHIP CAPACITOR B25V/16V 0.047µF-K
C2C1 141P142O90 CHIP CAPACITOR B25V/16V 0.047µF-K
C2C2 141P142O90 CHIP CAPACITOR B25V/16V 0.047µF-K
C2C3 141P142O90 CHIP CAPACITOR B25V/16V 0.047µF-K
C2C4 141P142O90 CHIP CAPACITOR B25V/16V 0.047µF-K
C2C5 154P344O10 CHIP CAPACITOR CH50V 180pF-J
C2C6 154P344O10 CHIP CAPACITOR CH50V 180pF-J
C2C7 154P344O10 CHIP CAPACITOR CH50V 180pF-J
C2D0 141P142O90 CHIP CAPACITOR B25V/16V 0.047µF-K
C2D1 141P142O90 CHIP CAPACITOR B25V/16V 0.047µF-K
C2D2 141P142O90 CHIP CAPACITOR B25V/16V 0.047µF-K
C2D3 141P142O90 CHIP CAPACITOR B25V/16V 0.047µF-K
C2D4 141P142O90 CHIP CAPACITOR B25V/16V 0.047µF-K
C2E0 141P144O20 CHIP CAPACITOR F16V 0.1µF-Z
C2E1 154P341O10 CHIP CAPACITOR CH50V 10pF-C
C2E2 154P341O30 CHIP CAPACITOR CH50V 12pF-J
C2E5 141P144O20 CHIP CAPACITOR F16V 0.1µF-Z
C2F1 181P520O10 CHIP ELE CAPACITOR 6.3V 22µF-M
C2F2 141P144O20 CHIP CAPACITOR F16V 0.1µF-Z
C2F3 141P144O20 CHIP CAPACITOR F16V 0.1µF-Z
C2F4 181P520O30 CHIP ELE CAPACITOR 6.3V 4.7µF-M
C2F5 141P144O60 CHIP CAPACITOR F16/10V 1µF-Z
C2F6 141P144O60 CHIP CAPACITOR F16/10V 1µF-Z
C2F7 141P144O60 CHIP CAPACITOR F16/10V 1µF-Z
C2G1 181P520O30 CHIP ELE CAPACITOR 6.3V 4.7µF-M
C2G2 141P144O20 CHIP CAPACITOR F16V 0.1µF-Z
C2G3 141P144O20 CHIP CAPACITOR F16V 0.1µF-Z
C2G4 141P144O20 CHIP CAPACITOR F16V 0.1µF-Z
C2G5 141P144O20 CHIP CAPACITOR F16V 0.1µF-Z
C2G6 141P144O20 CHIP CAPACITOR F16V 0.1µF-Z
C2G7 141P144O20 CHIP CAPACITOR F16V 0.1µF-Z
C2G8 141P144O20 CHIP CAPACITOR F16V 0.1µF-Z
C2G9 141P144O20 CHIP CAPACITOR F16V 0.1µF-Z
C2H0 141P144O20 CHIP CAPACITOR F16V 0.1µF-Z
C2H1 141P144O20 CHIP CAPACITOR F16V 0.1µF-Z
C2M9 141P144O20 CHIP CAPACITOR F16V 0.1µF-Z
C2N0 141P144O20 CHIP CAPACITOR F16V 0.1µF-Z
C2N1 141P144O20 CHIP CAPACITOR F16V 0.1µF-Z
C2N2 141P144O20 CHIP CAPACITOR F16V 0.1µF-Z
C2N3 141P144O20 CHIP CAPACITOR F16V 0.1µF-Z
C2N4 141P144O20 CHIP CAPACITOR F16V 0.1µF-Z
C2N5 141P144O20 CHIP CAPACITOR F16V 0.1µF-Z
C2P3 141P144O20 CHIP CAPACITOR F16V 0.1µF-Z
C2P4 141P144O20 CHIP CAPACITOR F16V 0.1µF-Z
C2P5 141P144O20 CHIP CAPACITOR F16V 0.1µF-Z
C380 181P522O60 CHIP ELE CAPACITOR 16V 47µF-M
C381 141P144O20 CHIP CAPACITOR F16V 0.1µF-Z
C382 141P144O60 CHIP CAPACITOR F16/10V 1µF-Z
C385 141P144O20 CHIP CAPACITOR F16V 0.1µF-Z
C386 141P144O20 CHIP CAPACITOR F16V 0.1µF-Z
C387 141P144O20 CHIP CAPACITOR F16V 0.1µF-Z
C388 141P144O20 CHIP CAPACITOR F16V 0.1µF-Z
C389 141P142O10 CHIP CAPACITOR B25V 0.01µF-K
C390 181P182O20
ELECTROLYTIC CAPACITOR 16V 470µF-M
C391 141P144O20 CHIP CAPACITOR F16V 0.1µF-Z
C392 141P144O20 CHIP CAPACITOR F16V 0.1µF-Z
C393 141P144O20 CHIP CAPACITOR F16V 0.1µF-Z
C394 181P182O20
ELECTROLYTIC CAPACITOR
16V 470µF-M
C395 141P144O20 CHIP CAPACITOR F16V 0.1µF-Z
C3A1 141P134O90 CHIP CAPACITOR F50V 0.1µF-Z
C3A2 141P143O80 CHIP CAPACITOR F50V 0.01µF-Z
C3A3 141P144O20 CHIP CAPACITOR F16V 0.1µF-Z
C3A4 181P182O00
ELECTROLYTIC CAPACITOR 16V 220µF-M
C3M0 154P355O20 CHIP CAPACITOR SL50V 470pF-J
C3M1 154P355O20 CHIP CAPACITOR SL50V 470pF-J
C3M3 154P355O20 CHIP CAPACITOR SL50V 470pF-J
C3M4 154P355O20 CHIP CAPACITOR SL50V 470pF-J
C400 181P520O10 CHIP ELE CAPACITOR 6.3V 22µF-M
C401 141P144O20 CHIP CAPACITOR F16V 0.1µF-Z
C402 141P144O20 CHIP CAPACITOR F16V 0.1µF-Z
C403 141P144O20 CHIP CAPACITOR F16V 0.1µF-Z
C404 141P144O20 CHIP CAPACITOR F16V 0.1µF-Z
C405 141P144O20 CHIP CAPACITOR F16V 0.1µF-Z
C406 141P144O20 CHIP CAPACITOR F16V 0.1µF-Z
C407 141P144O20 CHIP CAPACITOR F16V 0.1µF-Z
C408 141P144O20 CHIP CAPACITOR F16V 0.1µF-Z
C409 141P144O20 CHIP CAPACITOR F16V 0.1µF-Z
C410 141P144O20 CHIP CAPACITOR F16V 0.1µF-Z
C422 181P520O10 CHIP ELE CAPACITOR 6.3V 22µF-M
C424 141P144O20 CHIP CAPACITOR F16V 0.1µF-Z
C425 141P144O20 CHIP CAPACITOR F16V 0.1µF-Z
C426 141P144O20 CHIP CAPACITOR F16V 0.1µF-Z
C440 181P528O10 CHIP ELE CAPACITOR 4V 220µF-M
C441 141P144O20 CHIP CAPACITOR F16V 0.1µF-Z
C442 141P144O20 CHIP CAPACITOR F16V 0.1µF-Z
C443 141P144O20 CHIP CAPACITOR F16V 0.1µF-Z
C444 141P144O20 CHIP CAPACITOR F16V 0.1µF-Z
C445 141P144O20 CHIP CAPACITOR F16V 0.1µF-Z
C446 141P144O20 CHIP CAPACITOR F16V 0.1µF-Z
C447 141P144O20 CHIP CAPACITOR F16V 0.1µF-Z
C448 141P144O20 CHIP CAPACITOR F16V 0.1µF-Z
C449 141P144O20 CHIP CAPACITOR F16V 0.1µF-Z
C450 141P144O20 CHIP CAPACITOR F16V 0.1µF-Z
C451 141P144O20 CHIP CAPACITOR F16V 0.1µF-Z
C452 141P144O20 CHIP CAPACITOR F16V 0.1µF-Z
C453 141P144O20 CHIP CAPACITOR F16V 0.1µF-Z
C454 141P144O20 CHIP CAPACITOR F16V 0.1µF-Z
C455 141P144O20 CHIP CAPACITOR F16V 0.1µF-Z
C456 141P144O20 CHIP CAPACITOR F16V 0.1µF-Z
C457 141P144O20 CHIP CAPACITOR F16V 0.1µF-Z
C458 141P144O20 CHIP CAPACITOR F16V 0.1µF-Z
C459 141P144O20 CHIP CAPACITOR F16V 0.1µF-Z
C460 141P144O20 CHIP CAPACITOR F16V 0.1µF-Z
C461 141P144O20 CHIP CAPACITOR F16V 0.1µF-Z
C462 141P144O20 CHIP CAPACITOR F16V 0.1µF-Z
SYMBOL PA RTS
PARTS NAME DESCRIPTION
No. No.
SYMBOL PART S
PARTS NAME DESCRIPTION
No. No.
-
12 -
[S] : SL2U [X] : XL2U
