Mitsubishi XPANDER 2024

7
3. SRS air bag component location
SRS air bags system (location of air bags and related components) are located as shown in the figure below.
*: Refer to “10. Explanation of pictograms used”
SRS
warning lamp
Passenger’s (front)
air bag module
Driver’s air bag
module
Clock spring
SRS-ECU
Combination meter
Seat belt with
pre-tensioner (RH)
Seat belt with
pre-tensioner (LH)
Front impact sensor
