NOTE
Shut-off valve installed in fluid
dispensing hose () may be left open or
closed. When left open, fluid will begin to
flow once pump is operated. If closed,
pressure will build in reservoir as
indicated on gauge.
NOTE
Check vehicle’s service manual to
determine proper method to check
transmission fluid level.
Failure to follow manufacturer’s rec-
ommended procedure could result in
under- or over-filling transmission,
causing severe transmission damage.
Connect fluid dispensing hose () to res-
ervoir using quick-connect coupler ().
Close shut-off valve on fluid dispensing
hose ().
Push top lever () to center position.
Bleed off pressure by tilting pressure relief
knob ().
NOTE
Lifetime “sealed” transmissions require
use of special manufacturer recom-
mended fluids. Use of any other fluids
may cause severe damage to transmis-
sion and void manufacturer’s warranty.
Evacuate
sealed automatic
transmissions
NOTE
Verify quick-connect coupler sleeve
snaps to lock connection.
NOTE
Verify quick-connect coupler sleeve
snaps to lock connection.
Select appropriate ATF refill adapter for
application and connect to output of fluid
dispensing hose ().
Insert or connect ATF refill adapter to
transmission.
Pull top lever () back to build pressure in
reservoir until desired amount of fluid has
been dispensed.
Refill sealed
automatic
transmissions
Unscrew lid () from reservoir (), and
fill to desired level with new vehicle manu-
facturer’s recommended transmission
fluid (→ Fig. , page ; Fig. IPB , page
and Fig. IPB , page ).
Install lid () onto reservoir ().
NOTE
Prior to starting evacuation/refilling,
consult vehicle service manual for
recommended procedures, fluids and
capacities.
Connect fluid dispensing hose () to res-
ervoir using quick-connect coupler ()
(→ Fig. , page and Fig. IPB ,
page ).
Evacuate ATF from transmission
(→ To evacuate fluid, page 4).
