TAV. 2-1: Dimensions electro-valve / Dimensionen Magnetventile / Dimensions electrovanne /

Dimensiones electroválvula / Dimensione elettrovalvola

Fig.1

Fig.2

Pneumatic actuator / Pneumatikantrieb

/ Actionneur pneumatique / Mando

neumatico / Attuatore pneumatico

Fig. RAP080 RAP100 RAP125

Dimension electro-valve in line /

Dimensionen Magnetventile in Linie /

Dimensions electrovanne en ligne /

Dimensiones electroválvula en linea /

Dimensione elettrovalvola in linea

1 1,8" 1,8" 1,4"

Dimension electro-valve NAMUR /

Dimensionen Magnetventile NAMUR /

Dimensions electrovanne NAMUR /

Dimensioneselectroválvula NAMUR /

Dimensione elettrovalvola NAMUR

2 1,4" 1,4" 1,4"
