G3 Gryo 陀螺仪
Steering servo
转向舵机
Receiver
接收器
Spin the knob from the left to right, the gyro intervention gains value 0-100%.
旋钮从左到右调整陀螺仪介入增益值0-100%。
①GAIN
When the power on, long press the【SET】3 seconds, the LED from red to green
or from the green to red, it means the switch is successful. (Red LED is on for
Normal, Green LED is for Reverse)
通电状态下，长按3秒【SET】，LED颜色由红色变为绿色，或者由绿色变为红色，则代表已
切换成功。(LED红色常亮为反向，LED绿色为正向。)
1. Reverse/Normal Switching 正反向切换
a. Before power on, press and hold【SET】, then turn on the vehicle power (please
release【SET】 ASAP after turning on the power, if more than 5 seconds, it will
restore the factory setting), LED red flashing, it enters into the EPA setting.
b. Rotate the remote control rudder, turn the rudder to the desired position (to the
left or right), keep the current state, short press【SET】 then the green LED
flashing, it completes the single-side EPA setting.
2. EPA (End point adjustment) 行程调节
②SET 设置
!
The default direction of servo is Reverse. If not modified, please keep the
red constant LED light as normal state.
车辆标配的舵机方向为反向。如未做改装，请保持LED正常状态为红色常亮。
!
Before setting, please make sure the gyro direction is the same as the
direction of vehicle steering.
设置前请先确定陀螺仪方向与车辆转向的方向相同。
-6-
