Millermatic Python
®
Owner's Manual - page 11
Millermatic Compatible™ Python Head Assembly
No. Qty. Part No. Description No. Qty. Part No. Description
1 1 002-0629 Assy Cam Idler Arm 23 9 328-0012 Scr Shc 6-32 x 3/8
2 1 002-0631 Rear Body 24 4 333-0005 Wshr Spr LK #6
3 1 003-0857 Assy Trigger 25 1 336-0020 Scr Ph Phil 4-40 x 5/16 SST
4 1 003-2108 Assy Front Body 26 1 338-0153 Scr Shc 1-72
5 1 003-2125 Assy Knob Pot 27 6 411-0045 Tie Wrap
6 1 005-0701 Micro Swx Kit 28 1 421-0018 Pin Dowel 3/32 x 7/8 SST
7 1 003-2153 Assy Gun Boot 29 1 431-1622 Scr Shoulder 1/8 x 4/40
8 1 005-0695 Assy Speed Control Pot Kit 30 1 431-1637 Screw Hex 3/8-20 x 3/8
9 1 003-2147 Assy Barrel 60° AW 31 1 435-1585 Strap Motor
10 1 003-2241 Assy Power Pin Millermatic Compatible™ 32
1 005-0699
Handle Kit: Includes line items 28, 29,
and 34
11 4 336-0247 Screw, K40X12 Pan HD-Phl ST 33
12 1 437-0285 Housing, Pwr Pin Right Handle 34 1 437-0253 Door Molded
13 1 437-0286 Housing, Pwr Pin Left Handle 35 1 SEE TABLE Assy Gas Hose
14 1 419-0101 Strain Relief Spring 36 1 SEE TABLE Assy Conduit
15 1 437-0287 Spring Retainer 37 0.30 ft 737-0048 Tube Insulation 9 AWG, Clear
16 1 211-0077 Motor Pittman 38 1 751-0020 Cap Plug 0.218 ID x 0.50 LG
17 6 303-0096 O-Ring, .145 ID x .07 W 39
1 SEE TABLE Assy Power Cable
18 2 319-0254 Scr FH Phil 82 4-40 x 3/8 SST 40 1 SEE TABLE Assy Control Cable
19 1 319-0258 Scr FH Phil 82 4-40 x 5/8 SST 41 1 SEE TABLE Snake Skin
20 2 320-0084 Scr Button 4-40 x 3/16 ST 42 2 261-0094 Wrap Spiral Cord
21 1 003-2209 Assy Guide Wire 43 1 437-0268 Knob Cover
22 1 321-1104 Set Screw Mod 8-32
