10BAppendix B: Model Code Explanation 81BModel Code
91
Appendix B: Model Code Explanation
Model Code
The options for your transducer are identified in the model code when you order the unit. The
model code for your transducer is:
Model Number (DMA)
This designates the model number of the instrument as DMA.
Range (XX)
The full scale range is indicated by a 2-character code. It is expressed in Torr.
Full Scale Range
(mmHg/Torr)
Ordering
Code
0.02 U2 Only available on DMA (45° C) models.
0.05 U5 Only available on DMA (45° and 80° C) models.
0.10 .1
0.25 RE
1 01
2 02
5 05
10 11
(Continued on next page)
