81BModel Code 10BAppendix B: Model Code Explanation

Full Scale Range

(mmHg/Torr)

Ordering

Code

20 21

100 12

200 22

500 52

1000 13

Engineering Units (X)

The engineering units are indicated by a single letter code.

Units

Ordering

Code

Torr/mmHg T

mBar M

kiloPascal K

Pascal L

Fittings (XX)

Several types of fittings are available, designated by a 2-character code. No additional parts are

required.

Fittings

Ordering

Code

Straight Tube 50 O.D.

(1 K mmHg max)

Swagelok 8-VCR

(female)

Mini-CF (rotatable) HA

NW-16-KF

(5 K mmHg max)

Swagelok 8-VCO

(female)

NW-25-KF

(5 K mmHg max)

2¾-CF (rotatable) HC

Swagelok 4-VCR

(female)
