Genuine Accessories developed by MOBIS
Genuine Accessories developed by MOBIS
Fig 7
Fig 6b
mm
6Nm
FRONT REAR
700280
(27.56”)(11.02”)
mm
FRONT
Ceed Wagon
Xceed
REAR
750515
(29.53”)(20.28”)
210
Fig 6a
(8.27”)
J7211ADE01AL # 26.10.2023 REV04
Ceed SW
515mm
(20,3 )
750mm
(29,5 )
XCeed
280mm
(11,0 )
700mm
(27,6 )
Fig 6
Fig 5
= =
