Specification
Inputs and Outputs
• 6.35 mm / 1/4” TS dual-mono line outputs
• 6.35 mm / 1/4” TRS headphone output
• 3.5 mm / 1/8” TRS stereo audio input
• MIDI DIN In and Out
• 3.5 mm / 1/8” TS Analogue clock sync In and Out
• Class compliant MIDI over USB B connection
• 6.35 mm / 1/4” TRS expression pedal input
• 6.35 mm / 1/4” TS sustain pedal input
Enclosure and Display
• Tabletop-style enclosure, brackets for 19” 3U rackmount included (requires 1U free space
above or right-angled connectors)
• 1.54-inch large OLED display for instant visual feedback at all times of playing/editing
Power
• Power: DC-9.0V – 1.5A centre-positive
Editor Software
• Free MODALapp software editor available for macOS, Windows, iOS and Android
• MODALapp can also be run within your Digital Audio Workstation (DAW), with VST3 and
AU versions available
Dimensions (L x W x H)
• 384 x 127 x 81 mm / 15.1” x 5” x 3.2”
Weight
• 2.1 kg / 4.6 lbs
