7520’ Predator
Batwing Wing Deck Parts Section
Item Part Number Description Qty
1..............101-2003L .................20’ Bondiolli Wing - Left ............................................... 1
101-2003R ................20’ Bondiolli Wing- Right.............................................. 1
2..............108-2000 ..................15’/20 Wing Axle .......................................................... 1
3..............108-3030A ................15’/20 Single Spindle & Hub Assembly ...................... 1
108-3030 ..................15’/20’ Wing Axle Single Spindle Weldment ............ 1
415-0050-00 .............Hub Package ............................................................... 1
415-0051 ..................Single Spindle ............................................................... 1
4..............116-1833 ..................15’/20’ Hinge Rod Weldment .................................... 1
5..............401-2070 ..................Stump Jumper, Cen/Wing .......................................... 1
6..............116-9010L .................15’/20’ Wing Skirt- Left ................................................. 1
116-9010R ................15’/20’ Wing Skirt-Right ............................................... 1
7..............415-0013-21BW .......Gearbox 540 RPM (Right Wing) ................................. 1
415-0015-21BW .......Gearbox 540 RPM (Left Wing) .................................... 1
415-0013-20BW .......Gearbox 1000 RPM (Right Wing) ............................... 1
415-0015-20BW .......Gearbox 1000 RPM (Left Wing) .................................. 1
8..............116-1656 ..................Mower Deck Plug ........................................................ 1
9..............415-0007 ..................Safety Cone ................................................................. 1
10............159-1542 ..................Ratchet Jack & Handle ............................................. 1
11............457-1609 ..................Jack, Top Wind-5000 lb ............................................... 1
12............415-0011-20BW .......Wing PTO ...................................................................... 1
13............108-6065 ..................7’ HWY, 15’ & 20’ Skid (401-SKID7HWY) .................... 1
14............401-1003-20 .............Blade, LH Wing CW...................................................... 2
401-1003-21 .............Blade, CEN/Right Hand Wing CCW .......................... 2
15............108-7000 ..................Spring Locator .............................................................. 2
16............415-0025 ..................Compression Spring ..................................................... 2
17............415-2001 ..................Spring Suppressor Plug ................................................ 2
18............104-1905-WR ...........Wing Rubber Guard - Right ........................................ 1
104-1905-WL ............Wing Rubber Guard - Left .......................................... 1
19............104-2025 ..................Defl ector Strap ............................................................. 1
20............412-2083 ..................Bolt, ½”-13 x 2” ZP Gr5 ................................................. 17
21............412-0072-01 .............Flat washer, ½” ............................................................. 17
22............412-3243 ..................Nylock Nut, ½” ............................................................ 17
23............900-8614-01 ............. Jam Nut ........................................................................ 2
24............900-8771 ..................Lock Washer ................................................................. 2
25............830-1018NH ............. Washer W/Keyway ...................................................... 2
26............515-1011 ..................Nut, 36MM .................................................................... 1
27............515-1016 ..................Washer .......................................................................... 1
28............515-1010 ..................Cotter Pin ...................................................................... 1
29............412-0057-01 .............Blade Bolt, 1-1/8” ......................................................... 2
30............412-0657 ..................Hex Nut, 3/8” NC ......................................................... 4
31............412-0071 ..................Lock washer, 3/8” ........................................................ 4
32............412-0075 ..................Flat washer, 3/8” .......................................................... 4
33............412-03229 ................Plow Bolt, 3/8” x 1-1/2” GR5 ....................................... 4
34............412-15479-G ............Bolt, 1x8 Gr 8 w/ Grease Zerk ..................................... 1
35............415-0068 ..................Nylock Nut, 1” .............................................................. 2
36............412-15477-G ............Bolt, 1x7 Gr 8 w/ Grease Zerk .................................... 1
37............412-0076-01 .............Flat Washer, 5/8 Gr8 SAE ............................................. 6
38............412-3500 ..................Top Lock Nut, 5/8-18 .................................................... 12
39............412-0024 ..................Bolt, 5/8-18 x 2-1/2” NF ................................................ 6
40............105-114X78RD ......... Galvanized Rod ........................................................... 1
41............412-6298-6L .............¼” Safety Chain ........................................................... AR
---------------------------------- Option Only ---------------------------------------
42............BWREARCH-W20L ...Batwing Wing Rear Chain Guard, Left ...................... 1
................BWREARCH-W20R ...Batwing Wing Rear Chain Guard, Right ................... 1
43............108-5030A ................15’/20 Double Spindle & Hub Assembly ................... 1
108-5030 ..................15’/20’ Double Axle Single Spindle Weldment ........ 1
415-0050-00 .............Hub Package ............................................................... 1
415-0052 ..................Double Spindle ............................................................ 1
20 FT PREDATOR PARTS SECTION
