SELECTION OF THE PROPER KIT
3
75-537.7
Table 3.1 - High Altitude Kits for PTS/BTS Models
Table 3.2 - High Altitude Kits for PTC Models
Model
Size
Kit Details
Qty per
Kit
U.S.A Canada U.S.A. and Canada
2001-4500 ft 2001-4500 ft 4501-5500 ft 5501-6500 ft 6501-7500 ft
NAT PROP NAT PROP NAT PROP NAT PROP NAT PROP
150
Kit Suffix
- -45 -48 -45 -48 -45 -48 -46 -48 -47 -49
Item Code - 55776 55779 55776 55779 55776 55779 55777 55779 55778 55780
Orifice
6 43 54 43 54 43 54 44 54 45 55
Pressure Sw
1 NA NA NA NA NA NA NA NA NA NA
175
Kit Suffix
- -50 -53 -50 -53 -51 -53 -51 -53 -52 -54
Item Code - 55781 55784 55781 55784 55782 55784 55782 55784 55783 55785
Orifice
7 43 54 43 54 44 54 44 54 45 55
Pressure Sw
1 NA NA NA NA NA NA NA NA NA NA
200
Kit Suffix
- -55 -59 -55 -59 -56 -60 -57 -61 -58 -61
Item Code - 55786 55790 55786 55790 55787 55791 55788 55792 55789 55792
Orifice
7 41 53 41 53 42 1.50mm 2.35mm 1.45mm 2.30mm 1.45mm
Pressure Sw
1 NA NA NA NA NA NA NA NA NA NA
250
Kit Suffix
- -62 -67 -63 -68 -64 -69 -65 -69 -66 -70
Item Code - 55793 55798 55794 55799 55795 55800 55796 55800 55797 55801
Orifice
9 42 1.50mm 2.40mm 53 2.35mm 1.45mm 2.30mm 1.45mm 43 54
Pressure Sw
1 NA NA NA NA NA NA NA NA NA NA
300
Kit Suffix
- -71 -75 -71 -75 -72 -75 -73 -76 -74 -77
Item Code - 55802 55806 55802 55806 55803 55806 55804 55807 55805 55808
Orifice
9 37 52 37 52 38 52 39 1.60mm 40 53
Pressure Sw
1 NA NA NA NA NA NA Yes Yes Yes Yes
350
Kit Suffix
- -78 -82 -78 -82 -79 -82 -80 -83 -81 -84
Item Code - 55809 55813 55809 55813 55810 55813 55811 55814 55812 55815
Orifice
12 2.45mm 53 2.45mm 53 2.40mm 53 42 1.50mm 2.30mm 1.45mm
Pressure Sw
1 NA NA NA NA NA NA NA NA NA NA
400
Kit Suffix
- -85 -89 -85 -89 -86 -89 -87 -90 -88 -91
Item Code - 55816 55820 55816 55820 55817 55820 55818 55821 55819 55822
Orifice
12 37 52 37 52 38 52 39 1.60mm 40 53
Pressure Sw
1 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
Model
Size
Kit Details
Qty per
Kit
U.S.A. Canada U.S.A. and Canada
2001-4500 ft 2001-4500 ft 4501-5500 ft 5501-6500 ft 6501-7500 ft
NAT PROP NAT PROP NAT PROP NAT PROP NAT PROP
135
Kit Suffix
- -92 -94 -92 -94 -47 -49 -47 -49 -93 -95
Item Code
-
58152 58154 58152 58154 55778 55780 55778 55780 58153 58155
Orifice
6 2.15mm 1.35mm 2.15mm 1.35mm 45 55 45 55 47 1.25mm
Pressure Sw
1 NA NA NA NA NA NA NA NA NA NA
155
Kit Suffix
- -45 -96 -45 -96 -45 -48 -46 -48 -46 -94
Item Code
-
55776 58156 55776 58156 55776 55779 55777 55779 55777 58154
Orifice
6 43 1.45mm 43 1.45mm 43 54 44 54 44 1.35mm
Pressure Sw
1 NA NA NA NA NA NA NA NA NA NA
180
Kit Suffix
- -50 -61 -50 -61 -50 -53 -51 -53 -51 -97
Item Code
-
55781 55792 55781 55792 55781 55784 55782 55784 55782 58157
Orifice
7 43 1.45mm 43 1.45mm 43 54 44 54 44 1.35mm
Pressure Sw
1 NA NA NA NA NA NA NA NA NA NA
215
Kit Suffix
- -98 -70 -98 -70 -98 -101 -99 -101 -100 -102
Item Code
-
58158 55801 58158 55801 58158 58161 58159 58161 58160 58162
Orifice
9 44 54 44 54 44 1.35mm 2.15mm 1.35mm 45 55
Pressure Sw
1 NA NA NA NA NA NA NA NA NA NA
260
Kit Suffix
- -103 -68 -103 -68 -62 -68 -62 -69 -66 -69
Item Code
-
58163 55799 58163 55799 55793 55799 55793 55800 55797 55800
Orifice
9 41 53 41 53 42 53 42 1.45mm 43 1.45mm
Pressure Sw
1 NA NA NA NA NA NA NA NA NA NA
310
Kit Suffix
- -104 -84 -104 -84 -104 -106 -105 -106 -105 -107
Item Code
-
58164 55815 58164 55815 58164 58166 58165 58166 58165 58167
Orifice
12 43 1.45mm 43 1.45mm 43 54 44 54 44 1.35mm
Pressure Sw
1 NA NA NA NA NA NA NA NA NA NA
