4. TECHNICAL DATA TABLE – LAVA STONE GRILLS
TOTAL
POWER
kW
TOTAL GAS
CONSUMPTION
DIAMETER OF NOZZLES IN
HUNDREDTHS OF A
MILLIMETRE
MODEL
BURNERS
X POWER
No. x kW
MAX
MIN
LPG
G30 – G31
kg/h
NATURAL
GAS
G20
M³/h
LPG
G30 – G31
30mbar 37mbar
NATURAL
GAS
G20
20 mbar
65/40 GRL
1 x 5.5 5.5 2.5 0.427 0.582 120L 175L
65/70 GRL
2 x 5.5 11 5 0.854 1.165 120L 175L
BY-PASS
110 230
PILOT
19 27
PRIMARY AIR POSITION A mm =
10 10
4.1 GAS CHARACTERISTICS
The data relative to power and consumption refer to the following types of gas:
TYPE OF GAS NET HEAT
VALUE
(NHV)
PRESSURE
mbar
SUPPLY
mm water
G20 (
natural gas
) CH
4
9.45 kW m³/h 20 200
G30 (
butane
) C
4
H
10
12.68 kW/kg 30 300
G31
(propane
) C
3
H
8
12.87 kW/kg 37 370
G25
(G20L – DE)
8.12 kW m³/h 20 200
G25 (aardgas NL)
8.12 kW m³/h 25 250
When installing the appliances, the gas supply pressures must be those given above in
order to have maximum burner efficiency.
Pressure mbar = 1 millibar = 1 mbar = 10 mm c.d.a. (water column millimetres)
Power = 1 kW = 860 kcal = 3.6 MJ = 3412 BTU
THESE VALUES ARE
APPROXIMATE - ALWAYS MAKE
SURE THE FLAME IS REGULAR.
