• Changing the pilot nozzle (19):
remove the panel (12), unscrew the small pilot connecting pipe, change the nozzle,
inserting it and the small pilot connecting pipe in the nozzle holder together.
Check that there are no gas leaks by using a soapy water solution.
• Regulating the minimum flame:
remove the cock knob (8), use a screwdriver to turn the cock (6) adjustment screw (7)
until you get the minimum flame required.
Adjustment of minimum (Fig.2): (machines set up to use LPG and changed over to
natural gas)
Remove the knob (8) from the cock and use a screwdriver on the adjustment screw (7)
to tighten it all the way down.
• Supply pressure:
it must be that specified on the appliance’s data plate and in the instruction handbook
(see the Technical Data table). Check the supply pressure by inserting a rubber pipe,
with a water gauge or similar, in the pressure tap (10) welded on the gas shaft (9)
removing the screw (11). After it has been checked, tighten the screw. If the supply
pressure is different to that specified, find the cause and correct it.
7.2 CHANGING SPARE PARTS
Safety cock (6): remove the panel (12), unscrew the nut connecting the cock to the supply
shaft (9) and to the burner supply pipe, unscrew the thermocouple (15) and the pilot pipe
(16) from the cock, change the cock.
Thermocouple (15): remove the panel (12), unscrew the thermocouple (15) from the cock
(6) and from the pilot support (18) and then change it.
Ignition plug (20): remove the panel (12), unscrew the plug connection nut from the pilot
support (18). Remove the plug and change it.
Piezoelectric lighter (19): remove the panel (13), pull the plug connecting cable out (21),
remove the piezoelectric stop nut and change the lighter.
Pilot burner (18): remove the bottom panel (13), unscrew the pilot connecting nut (23), the
thermocouple (15), remove the ignition plug connecting nut, remove the pilot securing
screws and change the pilot. Now put everything back in place.
