13
MoJack EZ Max Lift
Push Pin
Push Pin
Lift Arm
Wheel Pad Lift Arm
Operating Instructions
STEP 3
Installing Wheel Pad Lift Arms
• Slide Wheel Pad Lift Arms
into both sides of the
Lift Arm and secure
with Push Pins.
STEP 4
Preparing the handle
• Push in side of handle
and rotate from storage
position to the operating
position. Allow to seat
into the locked position.
Wheel Pad Lift Arm
Locked Position
STEP 5
Familiarize yourself with the jack
• Practice raising and lowering the Lift Arm before attempting
to lift the mower (see Steps 10 – 13 on how to raise and lower
the Lift Arm).
• Practice Step 15 if you intend to raise or lower the
mower with a drill attachment.
NOTE: Remove all front mower attachments that interfere with
handle before using the lift.
When using the lift, keep ALL bystanders at a safe
distance away from the mower lift.
RAISE LOWER
To Next Page
