5.1 REMOVING/FITTING
CHEEK PADS
Prerequisite: in a seated position, place the helmet
upside-down on your knees.
To remove the cheek pads, grasp them at the bottom
and pull inwards to detach them from the velcro
1
.
Slide the plastic flap out of its position and remove
the cheek pads
2
.
To refit the cheek pads, insert the plastic flap into
its slots
3
and attach them to the velcro.
Make sure that the cheek pads are properly
fastened to the helmet.
3
1
2
