Monaco DIPLOMAT 2004 - BATTERY - CHASSIS

9 • 331
ELECTRICAL SYSTEMS - CHASSIS
DIPLOMAT 2004
The chassis battery operates only chassis and engine functions. The
chassis battery is a crank type battery, producing the high amperage needed
to start the engine. Engine starters initially require a large amount of current
to crank an engine. Initial starter amperage draw exceeds 1200 amps. The
type of application in which the engine battery is used differs from the house
battery application. The engine battery state of charge remains consistent.
Maintenance is still required with an engine battery. Regular electrolyte level
checks and hydrometer readings should be performed. High electrolyte
consumption, or inconsistent hydrometer cell readings, may indicate a
charging system problem. Perform a charging system and current draw check
if the battery is exhibiting abnormal hydrometer readings.
NOTE: Replacement batteries should have the same cold
cranking amp (CCA) rating.
BATTERY
- CHASSIS
BATTERY
SPECIFICATIONS
-CHASSIS
Voltage Specific Gravity State of Charge Depth of Charge
12.66 1.265 100% 0%
12.45 1.225 75% 25%
12.25 1.190 50% 50%
12.05 1.145 25% 75%
11.90 1.100 0% 100%
Battery State of Charge vs. Voltage / Specific Gravity
Voltage Reading: Battery fully charged at rest for one hour.
RC (25A @ 80° F)
minutes
12 Volt Chassis*
Group 31p - LHD (2 each)
6 Volt Domestic**
U2200 (4 each)
180 X 2 = 360
*Batteries connected in parallel. **Battery connections are made in a Series/Parallel connection.
†CCA Ratings are at 0º F. These are the minimum requirements.
75Amp@
80º F. = 230 Min.
450
Application
Ah (20hr)
CCA†
750
ISC 1250 CCA 12 VOLTS
CUMMINS ENGINE COLD CRANKING AMPS REQUIREMENTS
CCA Rating are at 0º F. These are the minimum requirements.
