Electrical Systems
-------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
3. Dock LTS:
Operates the side docking lights to increase visibility parking or backing.
4. Batt Boost:
The Battery Boost switch is used in the event the motorhome chassis battery
has been drained or is at a low charge level where the engine cannot start.
This switch momentarily “jumps” the house battery to the motorhome
domestic battery to assist in starting the engine. The boost switch used in
conjunction with engine starting procedures should not be held for more
than 30 seconds. This time period is long enough to prevent the boost
solenoid from over heating. The system works this way: A ground wire
comes off the front firewall to the battery boost switch; When the battery
boost switch is activated by pressing you will be sending a ground signal to
the rear of the coach through the 12 gauge orange wire to the 1,000 amp
solenoid. You should hear a loud clicking noise as the solenoid is being
activated. If the boost solenoid is inactive, locate the molex plug and start
the troubleshooting process by removing the cover on the dash. It may be
necessary to remove the wire from the battery boost solenoid and perform a
continuity check from the front to the rear of the motorhome.
5. Fog LTS:
Operates the fog lights with the ignition key on and the headlights in the low
beam position. The fog lights will go off when the headlights are switched to
high beam.
6. Fans HI/LO:
Operates the driver’s two speed dash fan for use with windshield
defrosting and cooling.
7. Fans HI/LO:
Operates the passenger’s two speed dash fan for use with windshield
defrosting and cooling.
8. Back up Monitor:
Used with the back up camera and will display the rear veiw of the
motorhome.
NOTE: Layouts will vary with difference in models.
5•167
