The ALL JACKS RETRACT mode or MANUAL mode can be engaged at
any time during automatic leveling operation.
Prior to automatic leveling it is essential that there is no movement in the
motorhome. To extend the jacks automatically proceed as follows:
• Place gear selector in NEUTRAL.
• Apply the parking brake.
• Turn ignition switch to the ON position.
• Switch the main jack control power switch ON.
• Press the AUTOMATIC LEVELING/ALL JACKS switch.
If the yellow lights illuminate, press down the rocker switch labeled AUTO-
MATIC LEVELING and release. The top green light will start blinking. After a
½ second delay, pump motor will come on and all jacks will extend downward.
The system will attempt complete leveling in one operation. The motorhome is
level when all yellow lights, as well as green lights, go out.
If leveling is unsuccessful on the first phase, the system will attempt to level
four subsequent times at seven second intervals.
If both green lights start flashing alternately, the motorhome has reached
maximum extension on one or more jacks. One or more yellow lights will blink,
indicating that additional height is required under one of the jack pads. This can
be attained by moving motorhome to another location or getting additional
height by placing a 2x8 block under one of the jack pads.
If you block under a jack pad, ONLY ONE JACK SHOULD BE BLOCKED
AT A TIME. If blocking a rear jack pad while motorhome is on a slope, oppo-
site set of rear wheels must be chocked to prevent rolling.
WARNING: Once jacks are extended down a red JACKS DOWN warning
light will blink and an alarm will sound. An alarm will sound again if jacks
are down and ignition switch is turned ON.
Once motorhome is level turn off POWER switch on control console and turn
off ignition switch. BEFORE DRIVING OFF, ALWAYS PERFORM A VISUAL
INSPECTION TO INSURE THAT JACKS ARE UP.
Automatic Retract:
Prior to retracting levelers it is advisable to start engine and build air pressure.
• Gear selector should be in NEUTRAL.
• Parking brake applied.
• Turn ignition switch to ON position.
• Engage power switch to ON position on jack control console.
• Press down rocker switch labeled ALL JACKS RETRACT and release.
CAUTION: Do not move motorhome while jacks are still in contact with
ground or extended, damage to jacks can occur. Do not raise any wheels off
the ground, which could result in damage to the motorhome.
Chassis Information
----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
EXECUTIVE7•245
Automatic
Leveling System
