If the step fails to operate:
• Make sure the step switch is
ON.
• Check the main power supply
for the step. A 20 amp auto
reset 12 Volt DC circuit
breaker is located on the rear
run plate.
• A magnetic door jam switch is
used to control step operation.
Use a separate magnet to apply
a “trigger” to the door jam
switch. Rotate test magnet to
align polarity field.
• A five amp ATO blade fuse is
used to illuminate the STEP
OUT dash warning light. The
fuse is located on the front run
plate.
WARNING: If the motorhome is driven with the step in the
extended position, there is the possibility of causing major
damage to both the step and the motorhome.
Clean all mud, salt and road grime from the step before lubricating.
Lubricate all moving parts (bearings, pivot points, slides, clevis pin, and the
drive linkage ball) every 30 days with a good quality heat and moisture
resistant penetrating grease. Kwik Lube Spray Grease is specially formulated to
lubricate Kwikee Electric Steps and it is also recommended for lubricating all
moving parts. Refer to the picture.
NOTE: Silicone lubricates and WD-40 are not recommended
as they have a tendency to evaporate and dry the mating sur-
faces which leaves them vulnerable to the elements.
Appliance & Equipment
------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
EXECUTIVE 3•50
