COMPONENT
DESCRIPTION
ASSEMBLY
BOOM ARM
BOOM BASE
UP & DOWN
BUTTON
POWER CABLE PORTABLE POWER PACK
ADDITIONAL EXTRA
BOLTS & ALLEN
KEY
LIFTING STRAP &
HOOK
SUPPORTING
BAR
HEIGHT LOCATING
SLOTS
RATCHET &
RATCHET LEVER
SECURING BAR
RELEASE &
SECURING CATCH
Lay all parts on the floor
Connect the Supporting bar
to the Securing bar
Using the 4 bolts supplied secure
the boom base to the securing bar with
the supplied Allen key
Place the boom base on top of the
securing bar ensuring that the bolt
holes are in line
