Mongoose M60i - Page 19

TURBO INTERFACE
To enable, remove the cover from the main module and remove the jumper between the m
ain IC
and the receiver board.
SENSOR PORT
The sensor port is a 4 pin input that accepts an impact sensor, ultrasonic sensor or microwave
sensor. A “Y” connector is available as an option where 2 sensors are required.
The M60B/M60S is supplied with a 2
stage impact sensor
–
other sensors optional.
The M60AU is supplied with an ultrasonic sensor.
The M60AM is supplied with a 2 stage microwave sensor.
