HOW TO OPERATE THE BO ATV
See Fig. U - On it are shown the different buttons:
1.Power button: Turn the power on and off.
2.Forward-reverse switch: Changes the direction of movement of the ATV.
● To move the vehicle forward, shift the lever to top position. If you release the foot pedal, the ATV will stop moving.
● To move the vehicle reverse, shift the lever to down position. If you release the foot pedal, the ATV will stop moving.
3.High-low speed switch: the ATV moves in high speed only in forward mode.
4.2W/4W switch (if equipped): Operates the vehicle to 2WD mode and 4WD mode.
5.Foot pedal: To move the vehicle, press the pedal down. To brake or slow down, release pressure from the pedal.
Use the handle bar to turn to the left or right.
6.Lights switch: Turn the front lights on and off.
7.Mp3 player – See Fig. MP:
A.USB slot
B.TF card slot (Read mp3 format only)
C.AUX input
D.Previous Song/ Increase volume
E.Play/ Pause
F.Next song / decrease volume
G.Change the audio input (If you insert two or more audio input devices).
H.Display screen: It displays the power level of the battery when the vehicle stops.
WARNING! IMPORTANT! Always stop the ATV when changing the direction of movement or the speed in order to avoid
damage of the gearboxes or motors.
15
•After each step you must check if each part is correctly placed and well fixed. Follow strictly each step and study well the
assembly figures.
•DO NOT over-tighten in order to avoid any damage.
1.Step 1 - Attach the Front Axle – See Fig. 1: Gently turn the vehicle body upside down. Fit the front axle to the vehicle
body. Insert the bend end of the steering column into the hole on the front axle linkage. Insert eight Ø4x16 screws through
the front axle and into the vehicle body, and tighten with a screwdriver. Fit a Ø10 plastic washer onto the bent end of the
steering column. Insert a split pin into the hole on the bent end of the steering column, bend the ends of the split pin back
using long nose pliers (not included).
2. Step 2 - Attach the Front Wheels - See Fig. 2: Fit a wheel driver to the front wheel and use four Φ 4x12 screws to
secure it. Put a gear box onto the front axle (“R” labeled fit to right side, “L” labeled fit to the left side.) Make sure the gear
box match up with the motor frame on the front axle as shown. Plug the connector on the motor in the connector on the
vehicle body. Put a front wheel onto the front axle. Make sure the driver on the front wheel matches the gear box on the front
axle. Put a Φ12 washer onto the front axle. Tighten a nut to the end of the front axle with a spanner. DO NOT over tighten.
Attach the wheel cover to the wheel. Repeat for the other front driving wheel.
3.Step 3 - Attach the Rear Driving Wheels – See Fig. 3: Put a wheel onto the rear axle. Ensure the wheel matches the
gear box. Put another Φ12 washer onto the rear axle. Tighten a nut to the end of the rear axle with a spanner. Repeat the
above procedure to assemble the other rear wheel to the rear axle. Repeat to fix the other rear wheel. HINT: An extra
spanner has been provided to hold the nut on the other side of the rear axle while tightening the nut on the other side. Attach
the wheel cover to the wheel.
4.Step 4 - Attach the Handle bar & Front decoration – See Fig. 4 & 5: Turn over the vehicle body. Fit the handle bar to
the end of the steering column. Line up the holes on the handle bar with those on the steering column. Fix using M5x27
screw and nut. Use pliers to hold the nut while tightening the screw on the other side with a screwdriver. Place the front
decoration to the vehicle body. Fix it using three Ø5x12 screws.
5.Step 5 - Attach the Front Roll Bar & Back Rest – See Fig. 6 & 7: Place the front roll bar to the vehicle body. Fix it with
four Ø4x16 screws and a screwdriver. Put the back rest at the rear part of the ATV. Fix it with two Ø4x16 screws.
6.Step 6 - Attach the Rear Decoration & Rear Roll Bar – See Fig. 8 & 9: Turn the rear decoration upside down. Attach
the rear roll bar to the rear decoration as shown. Insert the two Ø4x16 screws and tighten with a screwdriver. Place the rear
decoration with roll bar assembly over the rear of the vehicle body. Insert three Ø5x12 screws through the rear decoration
and into the vehicle body, tighten with a screwdriver. Insert two Ø4x16 screws through the real roll bar and into the vehicle
body, and tighten with a screwdriver.
7.Step 7 - Connect the Power Supply & Attach the Seat – See Fig. 10 & 11: Plug the battery connector into the red
connector of the vehicle cables as shown. Fix the tabs of the seat into the holes on the vehicle. Use a Ø4X16 screw to
secure the seat to the vehicle body.
