Parts List : MONO DX2 LED Deck Oven
(for use with following drawings)
F1 Heater MCB B872-22-008
F2 Heater MCB B872-22-008
F3 Heater MCB B872-22-008
F4 Control Power supply MCB B872-22-063
F5 Overheat Thermostat B888-30-014
F6 Cooling fan MCB B872-22-061
T1 Control circuit Power supply B801-93-004
K1 Top heat contactor B801-08-021
K2 Bottom heat contactor B801-08-021
Y1 Water solenoid B867-83-007
Y2 Damper solenoid B749-83-004
Q1 Mains isolator B851-07-002
U1 Main LED PCB 245-25-00100
U6 Interface PCB B728-93-014
R1 Top element 1.0Kw B854-04-003(B854-04-012 220v)
R2 Top element 0.6Kw B854-04-004(B854-04-013 220v)
R3 Top element 0.6Kw B854-04-004
R4 Top element 0.6Kw B854-04-004
R5 Top element 0.6Kw B854-04-004
R6 Top element 0.6Kw B854-04-004
R7 Top element 0.44Kw B854-04-036(B854-04-045 220v)
R8 Bottom element 1.0Kw B854-04-003(B854-04-012 220v)
R9 Bottom element 0.6Kw B854-04-004(B854-04-013 220v)
R10 Bottom element 0.6Kw B854-04-004
R11 Bottom element 0.6Kw B854-04-004
R12 Bottom element 0.6Kw B854-04-004
R13 Bottom element 0.6Kw B854-04-004
R14 Bottom element 0.6Kw B854-04-004
