Mono CLASSIC

FG245 RIGID DECK classic RevA17 11-04-17
30
OUTPUTS
PIN 1 – 24v
PIN 2 – TOP HEAT OUTPUT
PIN 3 -- TOP FRONT HEAT OUTPUT
PIN 4 – BOTTOM HEAT OUTPUT
PIN 5 – STEAM OUTPUT
PIN 6 – DAMPER OUTPUT
PIN 7 – LIGHT OUTPUT
PIN 8 – CANOPY FAN RELAY OUTPUT
PIN 9 – 24v
PIN 10 – 24v
CONTROLLER LAYOUT
