Mono FG158

MONO Bx Eco-connect Ovens 4/5/10-Tray | Steam Installation and Operation Manual
86
MONO FG0BX-UK-MAN-0200 | Rev. A21 (July 2021)
PART 4 / SECTION 4 – 4/5 TRAY 40 X 60 – WATER/STEAM SYSTEM
WATER INLET ASSY (INC. HOSE)
158-17-00400
PART 12
COPPER PIPE
A900-34-253
(10mm OD X 20 swg)
PART NUMBERS REFER TO DRAWING M158E25-75200 IN ELECTRICAL MANUAL
HOSE – BLUE (NOT SHOWN)
A900-34-087
BULKHEAD COUPLING
A900-34-321
(UNDER INSULATION)
FG153
