Monogram 15900-012 - Page 77

Monogram Sanitation
COMPONENT MAINTENANCE MANUAL
PN 15900-012 Series
38-31-07
Jan 10/95
FIG.
ITEM
AIRLINE
STOCK
NO.
NOMENCLATURE
1 2 3 4 5 6 7
EFF
CODE
-ITEM NOT ILLUSTRATED
PART NUMBER
UNITS
PER
ASSY
Page 1020
1
435
440
445
450
455
460
465
470
475
480
485
490
495
500
510
515
520
525
530
535
540
545
550
555
560
565
570
575
2435-14-18
4812-25
AN960C10L
MS35338-138
NAS679C3M
13503-106
MS51958-60
MS35338-138
AN960C10L
13451-036
13451-033
MS24693C269
2-034S604-70
MS29513-343*
4520-2*
AN507C632R5
4631-88
2393-21
4514
159000-175
13505-005
MS35649-264
CK05BX102K
PT8-6R
1488-6
MS35650-304
AN960C10L
P18-10R
.STRAP, GROUNDING
.STUD, GROUNDING
ATTACHING PARTS
. WASHER
. WASHER
. NUT
***
. TRANSMITTER, LIQUID
LEVEL (SEE IPL FIGURE 5
FOR DETAILS)
ATTACHING PARTS
. SCREW
. WASHER
. WASHER
***
. GASKET
. PLATE
ATTACHING PARTS
. SCREW
***
. O-RING (V02697)
. O-RING (V02697)
. SEAT ASSY
. . SCREW
. . HINGE
. . BUMPER
. . SEAT
. TANK AND TOP ASSY
. . CONTACT
. . NUT
. . CAPACITOR
. . NUT
. . TERMINAL (V06383)
. . LUG (V83330)
. . WASHER
. . TERMINAL (V06383)
1
1
4
1
1
1
3
3
3
1
1
4
1
2
1
5
1
2
1
1
4
1
1
1
2
1
2
1
