Monogram 15900-012 - Page 81

Monogram Sanitation
COMPONENT MAINTENANCE MANUAL
PN 15900-012 Series
38-31-07
Jan 10/95
FIG.
ITEM
AIRLINE
STOCK
NO.
NOMENCLATURE
1 2 3 4 5 6 7
EFF
CODE
-ITEM NOT ILLUSTRATED
PART NUMBER
UNITS
PER
ASSY
Page 1024
2
140
145
150
155
160
165
170
175
180
185
190
195
200
205
210
215
220
3516-009
MS51957-49
NAS620C8
NAS1291C08M
16006-031
16202-020
NAS1291C08M
AN960C8
16006-033
16006-032
14100-019
3514-003
MS24693C30
NAS620C6
NAS1291C06M
3516-001
3509-1*
.HOUSING, ANTISIPHON
ATTACHING PARTS
. SCREW
. WASHER
. NUT
***
. GASKET
. FLAPPER
. NUT
. WASHER
. GASKET
. WASHER, RETENTION
. TUBE, INLET
. FRAME ASSY
ATTACHING PARTS
. SCREW
. WASHER
. NUT
***
. PLATE, MOUNTING
. GASKET, MOUNTING PLATE
1
2
4
2
1
1
3
3
1
1
1
1
5
5
5
1
1
