Monogram 15900-012 - Page 84

Monogram Sanitation
COMPONENT MAINTENANCE MANUAL
PN 15900-012 Series
38-31-07
Jan 10/95
FIG.
ITEM
AIRLINE
STOCK
NO.
NOMENCLATURE
1 2 3 4 5 6 7
EFF
CODE
-ITEM NOT ILLUSTRATED
PART NUMBER
UNITS
PER
ASSY
Page 1027
3
-1
5
10
15
20
30
35
40
45
50
55
60
65
70
75
80
85
90
95
100
105
110
115
120
4650-23
MS24566-1B
MS24665-148
AN960C10L
MS9463-08
4811-174-1
AN960C2L
MS24665-18
4631-58-11
NAS679C3M
AN960C10L
4678-7
NAS679C06M
AN960C6
4682-3
RS62S
4651-6
2-11E515-80
NAS679C6M
4672-1
4801-11
4673
4801-12
4676-14
DRAIN VALVE ASSY (SEE IPL
FIG. 1 FOR NHA)
. PULLEY
ATTACHING PARTS
. PIN, COTTER
. WASHER
. PIN, CLEVIS
***
. PIN, DRILLED
. WASHER
. PIN, COTTER
. CABLE ASSY
ATTACHING PARTS
. NUT
. WASHER
***
. COVER ASSY
ATTACHING PARTS
. NUT
. WASHER
***
. SPRING
. SPIROLOX (V80756)
. HOUSING ASSY
. 0-RING (V02697)
. NUT
. PLATE
. SEAL
. PLATE, SUPPORT
. PLUG, SEAL
. VALVE STEM ASSY
RF
1
1
1
1
1
1
1
1
1
1
1
4
4
1
1
1
2
1
1
1
1
1
1
