Monogram 15900-012 - Page 86

Monogram Sanitation
COMPONENT MAINTENANCE MANUAL
PN 15900-012 Series
38-31-07
Jan 10/95
FIG.
ITEM
AIRLINE
STOCK
NO.
NOMENCLATURE
1 2 3 4 5 6 7
EFF
CODE
-ITEM NOT ILLUSTRATED
PART NUMBER
UNITS
PER
ASSY
Page 1029
4
-1
5
10
15
20
25
30
35
40
45
50
55
60
65
70
75
80
85
90
11059-79
11509-12-36
AN507C832R10
11059-12-33
NAS679C04M
AN960C4
MS35333-70
5411-23
MS51957-15
AD18-183
MS3470L12-3P
MS3416-12EN
1-480698-0
350690-1
MS35489-4
2333-7
11059-1
207360-1
66105-3
TIMER ASSY
(SEE IPL FIG. 1 FOR NHA)
. PLATE ASSY, TIMER
ATTACHING PARTS
. SCREW
***
. PC BOARD, TIMER
ATTACHING PARTS
. NUT
. WASHER
. LOCKWASHER
. LUG, TERMINAL, (V86928)
. SCREW
***
. DISCONNECT, FEMALE
(V59730)
. CONNECTOR
. CLAMP
. PLUG, CONNECTOR (V00779)
. PIN, CONNECTOR (V00779)
. GROMMET
. DECAL, I.D.
. ENCLOSURE, TIMER
. PLUG, CONNECTOR (V00779)
. SOCKET, CONTACT (V00779)
RF
1
2
1
2
3
1
1
2
2
1
1
1
2
1
1
1
1
2
