Monogram 15900-012 - Page 88

Monogram Sanitation
COMPONENT MAINTENANCE MANUAL
PN 15900-012 Series
38-31-07
Jan 10/95
FIG.
ITEM
AIRLINE
STOCK
NO.
NOMENCLATURE
1 2 3 4 5 6 7
EFF
CODE
-ITEM NOT ILLUSTRATED
PART NUMBER
UNITS
PER
ASSY
Page 1031
5-1
5
10
15
20
25
30
35
40
45
50
55
60
65
67
70
75
80
85
90
95
100
105
110
115
120
125
130
135
140
13503-106
13503-036
MS35275-217
5610-10-32
13503-011
1412-4
MS51957-13
5610-10-32
MS5649-44
13503-019
MS51957-13
AN960C4L
MS35338-135
MS35649-44
10-101949-14
M10SLRN
13503-018
13503-002
MS51957-21
5610-10-32
AN960C6
13503-012
1412-4
13503-009
13503-010
M10PLSN
13503-108
13503-109
13503-107
13503-001-00
LIQUID LEVEL TRANSMITTER
(SEE IPL FIG. 1 FOR NHA)
.CASE
ATTACHING PARTS
.SCREW
.WASHER, NYLON (V86928)
* * *
.SUPPORT
.LUG, GROUND (V81312)
ATTACHING PARTS
.SCREW
.WASHER, NYLON (V86928)
.NUT
* * *
.CONNECTOR
ATTACHING PARTS
.SCREW
.WASHER, FLAT
.WASHER, LOCK
.NUT
* * *
.GASKET, SIZE 14 (V9W339)
.RECEPTACLE (V81312)
.SEAL
.PLATE, MOUNTING
ATTACHING PARTS
.SCREW
.WASHER, NYLON (V86928)
.WASHER
* * *
.GROMMET
.LUG, GROUND WIRE (V81312)
.SPACER
.SPACER
.PLUG, CONNECTOR (V81312)
.PC BOARD, BRIDGE
.PC BOARD, LIGHT DRIVER
.DECAL, SCHEMATIC
.NAMEPLATE
RF
1
4
4
4
1
1
1
1
1
4
4
4
4
1
1
1
1
4
4
3
4
1
4
4
1
1
1
1
1
