Monogram Systems
COMPONENT MAINTENANCE MANUAL
BASIC PN 15900
38-31-09
Page 603/604
May 17/02
D. Timer Assembly
(1) Except for permissible repairs described in this section, repair of the timer
assembly is not considered practicable. Replace all parts that do not meet
CHECK requirements.
(2) Repair damage to painted surfaces of case and mounting plate as follows (refer
to Table 601 for repair materials).
(a) Lightly sand the damaged area with aluminum oxide abrasive cloth,
Federal Specification P-C-451, Grade 600, or finer, making certain to
feather edge of sanded area into surrounding painted area.
(b) Apply a primer coat, Specification MIL-P-23377 to exposed metal
surfaces.
(c) When dry, lightly sand primer as in step (a).
(d) Apply a finish coat of Gull Gray Gloss Lacquer, Color No. 32251,
Specification MIL-L-7178.
(e) Repair electrical wiring in accordance with standard shop practices.
