Monogram Systems
COMPONENT MAINTENANCE MANUAL
BASIC PN 15900
FIG.
ITEM
PART NUMBER
AIRLINE
PART NO.
NOMENCLATURE
1 2 3 4 5 6 7
USED
ON
CODE
UNITS
PER
ASSY
- ITEM NOT ILLUSTRATED
38-31-09
Page 1029
Feb 23/04
3
R -1 4650-24 DRAIN VALVE ASSY
(REPLD BY ITEM –1A)
(SEE IPL FIG. 1 FOR NHA)
A RF
R -1A 4650-31 DRAIN VALVE ASSY
(REPLS ITEM 1)
(SEE IPL FIG. 1 FOR NHA)
B RF
5 MS24566-1B . PULLEY 1
ATTACHING PARTS
R 10 MS24665-148 . PIN, COTTER A 1
R -10A MS24665-151 . PIN, COTTER B 1
R 15 AN960C10L . WASHER (REPLD BY ITEM 15A) A 1
R -15A NAS1149C0332R . WASHER 1
20 MS9463-08 . PIN, CLEVIS 1
***
30 4811-174-1 . PIN, DRILLED A 1
35 AN960C2L . WASHER A 1
40 MS24665-18 . PIN, COTTER A 1
45 4631-58-12 . CABLE 1
ATTACHING PARTS
50 NAS679C3M . NUT 1
R 55 AN960C10L . WASHER (REPLD BY ITEM 55A) A 1
R -55A NAS1149C0332R . WASHER 1
***
60 4678-7 . COVER 1
ATTACHING PARTS
65 NAS679C06M . NUT 4
R 70 AN960C6 . WASHER, FLAT
(REPLD BY ITEM 70A)
A 4
R -70A NAS1149CN632R . WASHER, FLAT 4
***
