Monogram Systems
COMPONENT MAINTENANCE MANUAL
BASIC PN 15900
FIG.
ITEM
PART NUMBER
AIRLINE
PART NO.
NOMENCLATURE
1 2 3 4 5 6 7
USED
ON
CODE
UNITS
PER
ASSY
- ITEM NOT ILLUSTRATED
38-31-09
Page 1031
May 17/02
4
-1 11059-79 TIMER ASSY
(SEE IPL FIG. 1 FOR NHA)
RF
5 11059-12-36 . PLATE ASSY, TIMER 1
ATTACHING PARTS
10 AN507C832R10 . SCREW, FLAT HD 2
***
15 11059-12-33 . PC BOARD, TIMER 1
ATTACHING PARTS
20 NAS679C04M . NUT 2
25 AN960C4 . WASHER 3
30 MS35333-70 . WASHER, lOCK 1
35 5411-23 . LUG, TERMINAL, (V86928) 1
40 MS51957-15 . SCREW, PAN HD 2
***
45 AD18-183 . DISCONNECT, FEMALE (V59730) 2
50 MS3470L12-3P . CONNECTOR 1
55 MS3416-12EN . CLAMP 1
60 1-480698-0 . PLUG, CONNECTOR (V00779) 1
65 350690-1 . PIN, CONNECTOR (V00779) 2
70 MS35489-4 . GROMMET 1
75 2333-7 . DECAL, I.D. 1
80 11059-1 . ENCLOSURE, TIMER 1
85 207360-1 . PLUG, CONNECTOR (V00779) 1
90 66105-3 . SOCKET, CONTACT (V00779) 2
