Monogram Systems
COMPONENT MAINTENANCE MANUAL
BASIC PN 15900
- ITEM NOT ILLUSTRATED
38-31-09
Page 1033
Feb 23/04
FIG.
ITEM
PART NUMBER
AIRLINE
PART
NO.
NOMENCLATURE
1 2 3 4 5 6 7
USED
ON
CODE
UNITS
PER
ASSY
5
R -1 13503-106 TRANSMITTER, LIQUID LEVEL
(REPLD BY ITEM –1A)
(SEE IPL FIG. 1 FOR NHA)
A RF
R -1A 13503-110 TRANSMITTER, LIQUID LEVEL
(REPLS ITEM 1)
(SEE IPL FIG. 1 FOR NHA)
B RF
5 13503-036 . CASE 1
ATTACHING PARTS
10 MS35275-217 . SCREW 4
15 5610-10-32 . WASHER, NYLON (V86928) 4
***
20 13503-011 . SUPPORT 4
25 1412-4 . LUG, GROUND WIRE 1
ATTACHING PARTS
30 MS51957-13 . SCREW 1
35 5610-10-32 . WASHER, NYLON (V86928) 1
40 MS35649-44 . NUT 1
***
45 13503-019 . CONNECTOR 1
ATTACHING PARTS
50 MS51957-13 . SCREW 4
R 55 AN960C4L . WASHER, FLAT
(REPLD BY ITEM 55A)
A 4
R -55A NAS1149CN416R . WASHER, FLAT 4
60 MS35338-135 . WASHER, LOCK 4
65 MS35649-44 . NUT 4
***
67 10-101949-14 . GASKET, SIZE 14 (V12143) 1
70 M10SLRN . RECEPTACLE (V81312) 1
75 13503-018 . SEAL 1
80 13503-002 . PLATE, MOUNTING 1
