Monogram Systems
COMPONENT MAINTENANCE MANUAL
BASIC PN 15900
38-31-09
Page 705
Feb 23/04
B. Motor-Pump-Filter Assembly, PN 3511-007 or 3512-007 (refer to IPL Figure 2)
(1) List of Materials
NOTE: Equivalent substitutes may be used for listed items.
ITEM IDENTIFICATION SOURCE
Lubricant Lubriplate 105 Fiske Bros., Refining Company
Newark, NJ 73219
Sealant Adhesive PS 890, CLASS B Courtaulds Aerospace
Glendale, CA
Lockwire MS20995C32 Any government approved source
(2) Procedure
(a) Apply a uniform film of sealant, PS 890, CLASS B to periphery of the
frame assembly (195). Install mounting plate (215) on frame assembly,
using screws (200), washers (205) and nuts (210).
(b) Install flapper (165) by pulling installation tail through hole in antisiphon
housing (140). Trim tail .010 - .030 from bulb if new flapper is being
used.
(c) Position retention washer in place on inlet tube (190) and install both with
gasket (180) on antisiphon housing (140), using washers (175) and nuts
(170).
(d) Install antisiphon housing (140) with gasket (160) on mounting plate
(215), using screws (145), washers (150) and nuts (155).
