IPA287Supplement Page 3 Monroe Electronics, Inc.
---V A30%M50%
28C 9.0V 34%RH
Main entrance display
+Decay
28C 9.0V 34%RH
Balance
28C 9.0V 34%RH
Null
28C 9.0V 34%RH
Press [+] and hold
less than 2 seconds
between 2-4 seconds
longer than 4 seconds
+ 1V Zeroing
28C 9.0V 34% M1+
+ 950V +Charge
28C 9.0V 34% M1+
+ 1V Zeroing
28C 9.0V 34% M2B
+1030V +Decay
28C 9.0V 34% M1+
+ 800V 3.6s
28C 9.0V 34% M1+
Manual
Test #1 (1-0)
+Decay
Manual
Test #2 (1-0)
Balance
+ 1V 5.2s
+0002mx –0004mn
Voltage update Balance duration timer
Min and Max voltages
start recording after 5 seconds.
Press [Enter] will abort any on-going test.
fter the test complete, review data begins.
Press [^] or [v] will scroll through the data.
Press [Enter] or [ON/OFF] back to Main
Manual Plus Decay Test
(press [^] button less than 2 seconds)
The 287 unit will start by zeroing then Charge to over +1050V, then Decay.
The decay timer starts at +1000V and stops at +100V.
Manual Balance Test
(press and hold [^] or [v] button for 2-4 seconds)
The 287 will start by zeroing, then Balance for the time duration. Start recording Min and Max
voltage levels after 5 seconds.
Up to 10 Manual test results can be stored in memory. They are named M1 thru M0 where M0 is
the 10
th
test.
Timer starts at
1000V and stops
at 100V
To Next Page
