3MONSTERTECH CHAIR MOUNT UNIVERSAL BASE INSTRUCTION MANUAL
UNIVERSAL CONNECTOR
M8x30
Nut M8
Ø8mm
35
8
25
8
M8x35 M8x25
BOLT DIMENSIONS AND HOW TO MEASURE THEM [mm]
