5MONSTERTECH CHAIR MOUNT UNIVERSAL BASE INSTRUCTION MANUAL
CHAIR MOUNT UNIVERSAL BASE ASSEMBLY
M8x16
Ø24
slot nut M8
if already attached
skip this step
