Moomba Mobius LS - Electrical Component Replacements; Fuse, Breaker, and Bulb Specifications

74
© 2009 Skier’s Choice, Inc.
2009 Moomba Electrical Replacements
Fuses
Under Dash
Ballast Main (3 Position)
Ballast Empty Pump (1 Position)
Ballast Fill Pump (1 Position)
Stereo
Wake Plate
Breaker
ATO
Breaker
ATM
Breaker
60 Amp
5 Amp
10 Amp
10 Amp
10 Amp
Type Size
Battery Connection
Amp Harness (5 Channel)
Amp Harness (4 Channel)
Amp Harness (2 Channel)
ANL
MAX
ATO
100 Amp
30 Amp
40 Amp
Back of Engine
Fuel Pump
Engine Ignition
Starter
ATM
ATM
ATM
20 Amp
20 Amp
20 Amp
Bulbs
Bow Light
Pole Light
Docking Lights
Tower Light Bar
Courtesy Lights
3175
906
MR16
H3
Sealed
12V8W
12V
50W 24 Degree
12V55W
(See Dealer)
