Moomba Outback LS - Page 45

45
© 2007 Skier’s Choice, Inc.
Bow Light
The bow light is located on the forward deck. To alert other
boaters to your position and direction while underway at
night, the light is green on the starboard side and red on
the port side. To replace the bulb, remove Phillips screw
to lift cover.
Stern Pole Light
Pole Light Receptacle
The removable pole light
is stored in the bow.
Always check for proper
alignment when inserting
the pole light into the
receptacle.
The pole light must
always be in place and
illuminated when visibility
is limited. The pole light
must be displayed while
under way from sunset
to sunrise. The pole light
must also be illuminated
while at anchor from
sunset to sunrise.
NOTE: Boats that are
equipped with factory
installed towers do
not have a stern light pole even though the rear light
receptacle is installed. If you would like a rear 360 pole
light so you may operate your boat after dark with the
WRZHUUHPRYHG\RXPD\SXUFKDVHRQHWKURXJK\RXU
dealer.
DO NOT pull skier with tow rope attached to ski pylon
while pole light is in place.
The pole light receptacle is located on the port side
deck near the stern. To install the pole light, open the
cover completely and with the plug correctly aligned,
slide it into the socket until the electrical contacts are
¿UPO\LQSODFH
Tower Pole Light
Boats equipped with factory
LQVWDOOHG WRZHUV WKH 
White Pole Light is mounted on
the tower. To raise the light,
pull the lever on the side of the
light and then carefully raise
the light to a vertical position.
Always lower the light after use
and before trailering to avoid
hitting low overhangs.
NOTE: If using tower pole
OLJKWGRQRWXVHVWHUQSROH
light.
To use the cleat,
pull center up.
DO NOT tow
objects with the
cleats.
Pop-Up Cleat
