12
57.Removecenterbezelpanel(1)withlicenselampcar
rier.
NOTE:Whileremovingthecarrierinthenextsteps,
usingasuitablepryingtool(1)todisengagethetabs
(3)fromthecarrieropening(2)beforeseparatingto
preventthetabsfrombeingbroken.
58.Placethebezelonabench.
59.Removetworetainingscrews(1).
60.Separateclips(2)fromcarrierusingprocedureshown
above.
Jun30,2011K6861197
