23
109.Ifequipped,installthelinkrod(1)endtotheliftgate
bypushingthelinkrod(1)ontotheliftgate(3).
110.Installtheplasticretainer(2)tothelockingmecha
nismfortheheadofthepowerliftgatelinkrod(1).
111.Positiontheleftquartertrimpanel(5)intothevehicle.
112.Connecttheauxiliarypoweroutletandpowerinverter
(2)wireharnessconnectors(3)(ifequipped).
113.Alignthetrimpanelovertheretainingslotsonthein
nerquarterpanel(1)andfirmlysnapintoplace.
114.Installthesixquartertrimretainingscrews.
115.Installthethirdrowupperturningloopanchorbolt.
116.Installthethirdrowlowerseatbeltwebbinganchor
(4).
117.Positionthequartertrimbolster(5)intothevehicle
andslidetherearseatbelt(3)intotheslot.
118.Alignthelocatingtabs(4)withtheholesintheleft
quartertrimpanel.
119.Carefullyengagethequartertrimbolsterupperre
tainingtabs(2)byinsertingthemintotheleftquarter
trimpanelandswingingthebottomedgeofthebolster
towardstheleftquartertrim.
120.Pushthequartertrimbolsterintotheleftquartertrim
paneluntiltheretainingclips(1)arefullyseated.
Jun30,2011K6861197
