1.
2.
3.
Pull out the freezer door and the upper
freezer drawer (G) to the final position.
Take out the ice storage box (H) by
lifting it up in the direction of the arrow.
Take out the upper freezer drawer (G)
by lifting it up from the rail system.
Disassembling the freezer door
H
G
G
Remove the lower freezer drawer (C)
by lifting it up.
Remove the 4 screws attached to the
supporting frame (D).
Pull out the freezer door and lift it upin
the direction of the arrow.
4.
5.
6.
D
C
Re-assembling the freezer door
To reattach the drawer after you moved
the appliance to its final location,
assemble the parts in reverse order.
9
