Taking in account and make use of all safety devices it is possible to change the glue.
The reason might be the choice of another type of glue. Never mix up different types of glue!
The factory filled glue can be ordered from supplier.
In case of a wrong set up of temperature for the type of glue in tank the glue might “burn out”.
After very long time of heating without using glue for binding the glue might be overheated.
In both cases the glue must be changed. (Glue only can be changed in melted condition!)
Outlet of Glue-Tank
Place card board box under shut
of outlet. (Steel can might become
hot – plastic can might melt!)
A 10 mm hexagon screw driver is
supplied with the accessory
package for opening the outlet
lock screw.
Release melted glue in card board box.
( Not included in accessory-package.( Use any one.)
3. How to change glue
3. How to operate the book thickness control
Max. Filling-Level of glue in Glue-assy:
Refill glue-substrate max. up to level of screws from
Spine-Scraper in picture left..
For main description please see section 4, point 8
The basic set of the handwheel is 90 which is related to a book with spine of 10 mm.
If the spine is smaller = turn the handwheel in UP-direction.
If the spine is thicker = turn the handwheel in DOWN-position.
Spine width and figures on handwheel scale:
Width of spine figure on
in mm(app) handwheel (app)
5 120
10 90
20 70 – 80
30 50 – 60
40 40 - 50
50 30 – 40
60 < 30
