4. Name of each part of machine
Function of each part.
1. Main Body and sections
Cover Station Glue Station Slitting/Fanning Station Clamp in loading position
Book Thickness Wheel Operator Main Panel
Main Switch
2. Main Switch (panel )
(Positioned on right hand side of machine)
Main Power Supply Switch ON - OFF
Main Fuse (Automatic/Resettable)
Check fuse whilst main power switch
is in OFF position
Slitting/Fanning-Assy-Switch ON - OFF
