mori seiki NL3000 User Manual

2-553MACHINE OPERATIONS OPERACIONES DE MECANIZADO
(Q40061 001)
No.
N°
Symbol
Símbolo
Order No.
N° de pedido
Parts Name
Designación de la pieza
Q'ty
Ctd.
Maker
Fabricante
1 • * U00531A Oil Tank 10 L 1 DAIKIN
2 * * Oil Level Gage DHA-06-150 1 DAIKIN
3 * * Oil Level Gage KLA-80A 1 DAIKIN
5 * * Oil Filler Port/Air Breather HY-06T 1 DAIKIN
6 * * Oil Cooler 1734294-01 1 DAIKIN
8 • * U00536A Manifold BT-202-50-S 1 DAIKIN
9 • * U00537A Manifold BT-102-50-S (UK4619) 1 DAIKIN
10 * * A Port Pilot Controlled Check Valve MP-02A-20-55 1 DAIKIN
11 YV80, YV81 * Solenoid Valve KSO-G02-2DA-30-E 1 DAIKIN
12 * * Orifice φ2.1 (K02-021) 1 DAIKIN
13 * * P Port Check Valve MC-02P-05-65 1 DAIKIN
14 YV171 * Solenoid Valve KSO-G02-2BA-30-E 1 DAIKIN
15 • * U00532A Manifold BT-102-50-S (UK4273-1) 1 DAIKIN
16 • * U00530B Manifold BT-202-50-S (UK4276-1) 1 DAIKIN
17 * * P Port Reducing Valve MG-02P-03-55-T-74 1 DAIKIN
18 * * Gage Block Y4322963 1 DAIKIN
19 YV10, VY11 * Solenoid Valve KSO-G02-2DA-30-E 1 DAIKIN
20 * * Pressure Gage YSPA1/4R × φ60 × 6 MPa (PS0779-SN) 1 DAIKIN
21 * * P Port Reducing Valve MG-02P-03-55-T-74 1 DAIKIN
22 * * Pressure Gage Y4322963 1 DAIKIN
23
YV120,
YV121
* Solenoid Valve KSO-G02-2DA-30-E 1 DAIKIN
24 * * Pressure Gage YSPA1/4R × φ60 × 6 MPa 1 DAIKIN
25 * P27323A High Pressure Hydraulic Hose NWP70 9*320 (3/8) 1
OSAKA
KOUATSU
26 * P27324A High Pressure Hydraulic Hose NWP70 12*350 (1/2) 1
OSAKA
KOUATSU
27 * P27***A High Pressure Hydraulic Hose NWP70 9*4130 (3/8) 1
OSAKA
KOUATSU
28 * P27***A High Pressure Hydraulic Hose NWP70 9*4130 (3/8) 1
OSAKA
KOUATSU
29 * P27331A High Pressure Hydraulic Hose NWP70 9*950 (3/8) 1
OSAKA
KOUATSU
30 * P27380A High Pressure Hydraulic Hose NPW70 9*1000 (3/8) 1
OSAKA
KOUATSU
31 * P29101A Braid Hose ST-25 × 4250 L (φ25) 1 TOYOX
32 * P27***A High Pressure Hydraulic Hose NWP70 9*6200 (3/8) 1
OSAKA
KOUATSU
33 * P27***A High Pressure Hydraulic Hose NWP70 9*6100 (3/8) 1
OSAKA
KOUATSU
34 * P27***A High Pressure Hydraulic Hose NWP70 9*6500 (3/8) 1
OSAKA
KOUATSU
