Battery
15
Mounting the Battery:
• Hold the battery grip and plug in the battery with the battery bottom aligned to the mouth of the
battery holder. When a click sound is heard, the battery has been mounted correctly.
Charg ing the Battery:
The battery can be charged with normal AC power (AC 110-220 V, 50-60 Hz). The charging port is
located under the front part of the control panel. Before charging, ensure the chair is powered off.
• P lug the charger 3 – pin cable into the charging port under the front part of the j oystick
controller (as seen below).
• P lug the charger into a power outlet. When the red LED is on, it is charging.
• When the LED on the charger changes from red to green, keep charging for an additional 30
minutes to allow the battery to be fully charged.
• Unplug the charger from the power outlet before unplugging from the charging port of the
j oystick controller.
